Fixing Accessories

MPM supplies high-performance, long-lasting fixing accessories that reduce damage to the floor. It offers a wide range of fixing accessories in order to best meet the customer’s space and durability requirements.

Our team of experts and technicians is available to help identify the fixing accessory that can guarantee the best performance based on the product, the industry of application and the place of installation.

S12

Image of an S12 Screw Fixing Accessory for Protection Systems

Fixing Accessories

Ø12mm alternative screw for FIX P 90 and 150, GRINCO 90 and GRINCO 150 plates. advantages: greater resistance, smaller footprint; no chemical anchor required; reusable up to 3 times ensuring the same resistance; quick and easy fixing and sealing less affected by the right tightening torque and by the cleaning of the hole.

S16

Image of an S16 Screw Fixing Accessory for Protection Systems

Fixing Accessories

Ø12mm alternative screw for GRD200. Advantages: greater resistance, smaller footprint; no chemical anchor required; reusable up to 3 times ensuring the same resistance; quick and easy fixing and sealing less affected by the right tightening torque and by the cleaning of the hole.

B12

Image of an B12 Screw Fixing Accessory for Protection Systems

Fixing Accessories

Bush with Ø12mm screw. Fixing available with FIX P 90 and 150, GRINCO 90 and GRINCO 150 plates. Advantages: greater resistance, reusable for an endless number of times; smaller footprint; no risk to the floor. Floor hole smaller than SF12 fixing.

B16

Image of an B16 Screw Fixing Accessory for Protection Systems

Fixing Accessories

Bush with Ø16mm screw. Fixing available for products: GUARD RAIL 90 and COPRO 90. To be fixed with a chemical anchor. Advantages: greater resistance, reusable an endless number of times; smaller footprint; no risk to the floor; fast fixing; floor hole smaller than SF16 fixing.

B20

Image of an B20 Screw Fixing Accessory for Protection Systems

Fixing Accessories

Bush with Ø20mm screw. Alternative fixing for ROD 70, GUARD RAIL 150, TRUCK LINE 150 and COPRO 150. To be fixed with a chemical anchor. Advantages: greater resistance, reusable an endless number of times; smaller footprint; no risk to the floor; fast fixing.

SF12

Fixing Accessories

Ø12mm threaded bar including nut and washer. To be fixed with chemical anchor. Combinable with FIX P 90 and 150, GRINCO 90 and GRINCO 150 plates. Advantages: greater resistance, reusable for an endless number of times; smaller footprint; no risk to the floor.

SF16

Fixing Accessories

Ø16mm threaded bar including nut and washer. Alternative available for GUARD RAIL 90 and COPRO 90 products. To be fixed with a chemical anchor. Advantages: greater resistance, reusable for an endless number of times; smaller footprint; no risk to the floor.

SF20

Fixing Accessories

Ø20mm SF20 stainless steel threaded bar. To be fixed with a chemical anchor. Fixing supplied with Guard rail 150, Truck line and Copro 150 products. Advantages: high resistance.

S12FH

Fixing Accessories

Ø12mm alternative anchor screw with countersunk head for FIX P 150 COUNTERSUNK plates. Advantages: greater resistance, no risk of impacts or damages to the screw as it does not protrudes out the plate; no chemical anchor required; reusable up to 3 times ensuring the same resistance; quick and easy fixing and sealing less affected by the right tightening torque and by the cleaning of the hole..

M12

Image of an M12 Mechanical Anchor Fixing Accessory for Protection Systems

Fixing Accessories

Mechanical anchor Ø 12mm. Fixing supplied with FIX P 90 and 150, FIX P RACK CORNER, GRINCO 90 and GRINCO 150 plates. Advantages: fast and easy fixing; high resistance

M16

Image of an M16 Mechanical Anchor Fixing Accessory for Protection Systes

Fixing Accessories

Ø16mm galvanised mechanical anchor supplied with the Full Frame Base plate and with GUARD RAIL 90 and COPRO 90 products. Advantages: fast and easy fixing; high resistance

AA12

Fixing Accessories

Fixing system for asphalt. Fixing available for plate FIX P 90 and 150, GRINCO 90 and GRINCO 150, COVER 90 RE and COVER 150 RE. Floor hole required Ø22mm. It requires the asphalt chemical anchor.

AA16

Fixing Accessories

Fixing system for asphalt. Fixing available for GR 90. Floor hole required Ø22mm. It requires the asphalt chemical anchor.

FIX KIT ROD 70

Fixing Accessories

Fixing kit supplied with the ROD 70 bollard. the kit includes a Ø20mm M20 galvanized threaded bar, nuts, washer and spring washer. To be fixed with a chemical anchor. Advantages: high resistance; possibility of removing and replacing the bollard at the same point of installation and replacing the threaded bar.

FIX KIT ROD 70 INOX

Fixing Accessories

Fixing kit supplied with the ROD 70 bollard. the kit includes a Ø20mm M20 stainless steel threaded bar, nuts, washer and spring washer. To be fixed with a chemical anchor. Advantages: high resistance; possibility of removing and replacing the bollard at the same point of installation and replacing the threaded bar; anti-corrosion and resistant to the most aggressive chemicals.

FIX KIT ROD 120

Fixing Accessories

Fixing kit supplied with the ROD 120 bollard. the kit includes a Ø30mm galvanized M30 threaded bar, nuts, washer and spring washer. To be fixed with a chemical anchor. Advantages: high resistance; possibility of removing and replacing the bollard at the same point of installation and replacing the threaded bar.

FIX KIT ROD120 INOX

Fixing Accessories

Fixing kit supplied with the ROD 120 bollard. the kit includes a Ø30mm stainless steel M30 threaded bar, nuts, washer and spring washer. To be fixed with a chemical anchor. Advantages: high resistance; possibility of removing and replacing the bollard at the same point of installation and replacing the threaded bar; anti-corrosion and resistant to the most aggressive chemicals.

M16 INOX

Fixing Accessories

Ø 16mm stainless steel mechanical anchor. Alternative fixing for GUARD RAIL 90 and COPRO 90 products. Advantages: fast and easy fixing; high resistance; anti-corrosion and resistant to the most aggressive chemicals.

TS9

Image of a TS9 Rivet Fixing Accessory for Protection Systems

Fixing Accessories

Rivet to fix caps and corner pieces to be combined with the WP100 and WP 150 protection profile.

TM5

Image of a TM5 Screw Cap Fixing Accessory for Protection Systems

Fixing Accessories

Screw cap to be combined with WPT100 and WPT150 products.

TF14

Fixing Accessories

Percussion rivet to fix terminals and corner pieces to be combined with the Kerb 200 protection profile. Rivet head without hole.

TB14

Fixing Accessories

Rivet to fix terminals and corner pieces to be combined with the Kerb 200 protection profile..

TF20

Fixing Accessories

Percussion rivet to fix terminals and corner pieces to be combined with the Kerb 300 protection profile. Rivet head without hole.

TB20

Fixing Accessories

Rivet to fix terminals and corner pieces to be combined with the Kerb 300 protection profile.
